Asset Status - RTA Web
The Vehicle Status sets the availability of each asset so that, at a glance, any user can see the overall current health or position on the asset. These statuses are set between “Available” and “Unavailable,” and can be color-coded specific to the operation’s preferences.
While Vehicle Status can be seen in RTA Web and edited through Work Order Lines (more on that below), the initial settings and availability of this feature are controlled in RTA Classic.
Settings and Controls in RTA Classic
Setting adjustments for status can be done through RTA Classic only at this time. To view the Vehicle Statuses currently displaying/in use in RTA follow the below process.
Open RTA Classic
Click on the System Pulldown
Click on Set Up System Switches
Click on System Codes
Enter Level 3 Password
Click on the Vehicle Status Tab
To Edit a Code, double click on a line item and change the features such as the code, description, and/or color palette and then click OK
To create a code, follow steps 1-4 above and click on Add Code. Input the preferred status code, description, and set color palette and then click ok
Switch controlling Vehicle Status in RTA
Vehicle Statuses are set through either the vehicle master file in RTA Classic or through the Work Order lines in RTA Web and RTA Classic. This preference is identified from System Switch SSM Misc.1 #39.
If the switch is set to Automatic, then the true vehicle status will be identified through the Work Order screen. When all work order lines are completed, the vehicle status will ‘Automatically’ reset to Available.
If the switch is set to Manual, then the only way to update the true vehicle status will be in the vehicle master screen in RTA Classic, under the General Tab.
To set the switch follow the below process.
Click on the System Pull Down in RTA Classic
Click on Set Up System Switches
Click on Main System Parameters
Enter Level 3 Password
Miscellaneous I tab
Enter 39 for the line number at the bottom and hit enter
Choose either Manual or Automatic based on the descriptions above
Click OK
RTA Web and Vehicle Status
Vehicle Status is initially set when adding the vehicle into RTA Web and can be viewed in the Vehicle File in RTA Web at any time.
Vehicle Status cannot be updated through the vehicle file in RTA Web at this time
Vehicle Status is updated via Work Orders in RTA Web – Refer to Work Order Lines for instructions on Work Orders in RTA Web
Status can also be edited in the Classic version – Refer to Adding an Asset for instructions on Classic status editing under the General Tab section
